Metal Frame Composite Vibrating Screen Mesh

Product Overview

Metal Frame Composite Vibrating Screen Mesh is a composite screening medium integrating woven steel wire screen cloth and vulcanized rubber border frame. The high strength steel wire mesh provides precise aperture control and excellent tensile strength, while the bonded rubber frame absorbs vibration impact, reduces noise and prevents wire breakage at the clamping edge.

Different from ordinary woven wire screens, the metal-rubber composite frame simplifies tensioning and mounting on vibrating screen decks. It effectively resists frequent vibration fatigue, extends service life and avoids premature edge tearing. Available in multiple aperture sizes and wire diameters, this composite screen mesh handles fine and medium grading, dewatering and scalping tasks for both dry and wet materials. It is a reliable choice for mineral processing, quarry aggregate production, coal preparation and construction material screening.

Key Features

Technical Specifications

Stainless Steel Screen Composite Screen Mesh

Specifically designed for solid-liquid separation in oil drilling fluid applications, this multi-layer functional filter mesh is composed of stainless steel wire mesh of different mesh sizes through a special composite process, typically comprising a support layer, a filtration layer, and a protective layer.

• Support Layer: Constructed from high-stiffness stainless steel wire mesh, ensuring structural stability under high-frequency vibration (1,500–3,000 times per minute) and high-pressure drilling fluid impact.
• Filter Layer: Formed through precision weaving to achieve uniform pore sizes (20–300 mesh options), precisely intercepting rock debris particles ranging from 0.075 to 1.2 mm in drilling fluid.
• Protective Layer: Constructed from acid- and alkali-resistant stainless steel material to withstand corrosion from corrosive media such as hydrogen sulfide and chloride ions in drilling fluid, thereby extending service life.

Stainless steel composite mesh features a gradient pore size design for graded filtration, with the upper layer intercepting large particles to prevent blockages and the lower layer providing fine filtration to enhance separation efficiency. Additionally, the composite manufacturing process ensures the surface flatness deviation is controlled within 0.5 mm/m, ensuring tight adhesion to the vibrating screen frame and minimizing secondary wear caused by resonance.
